Technical Specifications

• Effective Volume: 1000L / 10HL

• Material: Food-grade SUS304 / SUS316L stainless steel

• Design: 60° conical bottom for optimal yeast removal

• Pressure Rating: 2 bar working / 3 bar test pressure

• Cooling Zones: Independent glycol jackets (cone + cylinder)

• Insulation: 100mm PU foam for thermal stability

• Surface Finish: Internal Ra < 0.6μm, mirror-polished welds

• Manway: Side or top-mounted shadowless manhole

Key Features

1. Professional Brewing Performance

• Full-size CIP arm with spray ball for efficient internal cleaning

• Tri-clamp connections for CO₂ inlet, sampling, and carbonation

• PRV and spunding valve for pressure fermentation control

2. Hygienic and Durable

• Sanitary welds with passivation treatment

• Butterfly valve and dump port for yeast harvesting

• Optional carbonation stone, level indicator, and sample valve

3. Scalable Brewing Operations

• Matches batch sizes from 5HL–10HL brewhouses

• Supports single or double batching

• Compatible with modular brewhouse expansions

Brewing Applications

• Primary fermentation of ales and lagers

• Cold crashing for clarity and stability

• Secondary fermentation and conditioning

• Yeast harvesting for re-pitching

Why Tonsen?

• 15+ years of brewery equipment manufacturing experience

• Tanks in 50+ countries serving craft breweries worldwide

• Custom-built to fit your space and brewing process

• Certified to ASME, PED, CE standards

• OEM branding and engineering support

FAQ – 10HL Fermenter

Q: Can I carbonate in this fermenter?
A: Yes, it’s pressure-rated and compatible with in-tank or inline carbonation.

Q: Is the insulation suitable for cold lager fermentation?
A: Yes, 100mm PU foam keeps temperatures stable for extended periods.

Q: Can I use this tank for sours or mixed fermentation?
A: Absolutely — the sanitary finish makes cleaning between batches easy.
